Cranes for Hire at Caledonian Cranes, Scotland. 4

Maeda Cranes and Lifts for Hire

This is an overview of the Maeda cranes that are available for hire at Caledonian Cranes.

Maeda Cranes at a Glance.

Summary detail of capabilities are shown below.

You can also download a pdf with detailed information on each model of Maeda Crane.

Maeda MC104C

Cranes for Hire at Caledonian Cranes, Scotland. 5

Technical Data
Capacity: 0.995t x 1.1m
Max lifting Height. 5.5m
Machine weight 1,150kg

Cranes for Hire at Caledonian Cranes, Scotland. 6

MAEDA MC174C

Cranes for Hire at Caledonian Cranes, Scotland. 7

Technical Data
Capacity: 1.72t x 1.0m
Max lifting Height. 5.5m
Machine weight 1,290kg

Cranes for Hire at Caledonian Cranes, Scotland. 6

MAEDA MC285C-3

Maeda MC285C

Technical Data
Capacity: 2.82t x 1.4m
Max lifting Height. 8.7m
Machine weight 1,990kg - 2,160kg

Cranes for Hire at Caledonian Cranes, Scotland. 6

MAEDA MC305C

Cranes for Hire at Caledonian Cranes, Scotland. 10

Technical Data
Capacity: 2.98t x 2.5m
Max lifting Height. 12.52m
Machine weight 3,900kg (4,080kg with electric motor)

Cranes for Hire at Caledonian Cranes, Scotland. 6

MAEDA MC405C

Maeda MC405C

Technical Data
Capacity: 3.83t x 2.7m
Max lifting Height. 16.8m
Machine weight 5,600kg (5,750kg with electric motor) (Fly jib: +150kg)

Cranes for Hire at Caledonian Cranes, Scotland. 6

MAEDA MC815C

Maeda MC815C

Technical Data
Capacity: 8.09 x 2.4m
Max lifting Height. 19.6m
Machine weight 9,460kg (9,700kg with electric motor)

Cranes for Hire at Caledonian Cranes, Scotland. 6

MAEDA MK1033CW-1

Maeda MK1033CW

Technical Data
Capacity: 0.995t x 1.3m
Max lifting Height. 11.3m
Machine weight 2,270kg - 2,390kg

Cranes for Hire at Caledonian Cranes, Scotland. 6

MAEDA CC423S-1

Maeda CC423S-1

Technical Data
Capacity: 2.93t x 1.5m
Max lifting Height. 9.46m
Machine weight 4,400kg

Cranes for Hire at Caledonian Cranes, Scotland. 6

MAEDA CC985S-1

Maeda CC985S-1

Technical Data
Capacity: 4.9t x 2.1m
Max lifting Height. 16.5m
Machine weight 9,450kg

Cranes for Hire at Caledonian Cranes, Scotland. 6

MAEDA CC1485S-1

Maeda CC1485S-1

Technical Data
Capacity: 6t x 2.6m
Max lifting Height. 22m
Machine weight

14,400kg

(14,700kg with fly jib)

Cranes for Hire at Caledonian Cranes, Scotland. 6

MAEDA CC1908S

Maeda-1908

Technical Data
Capacity: 8.1 t x 2.6m
Max lifting Height. 20.1m

Max. Working Radius

19.3m

Cranes for Hire at Caledonian Cranes, Scotland. 6

Tracked Carriers

Tracked Carriers for Hire

UK designed and built, Tracked Carriers produce versatile load bearing carriers with a wide range of attachments and an infinite amount of uses.

Beaver 350e

Cranes for Hire at Caledonian Cranes, Scotland. 19

  • 350kg capacity
  • 350kg capacity
  • 700mm wide
  • 285mm high
  • Battery powered
  • 2 speed remote control
  • 45° gradeability (100%)
  • 1.5km/h maximum speed

Cranes for Hire at Caledonian Cranes, Scotland. 6

700 R / 700 PRO

700 Pro

  • 700kg capacity
  • 600mm wide
  • 355mm high
  • Battery powered
  • Fully proportional remote control
  • 45° gradeability (100%)
  • 3.5Km/h maximum speed

Cranes for Hire at Caledonian Cranes, Scotland. 6

1200 R / 1200 PRO

Cranes for Hire at Caledonian Cranes, Scotland. 22

  • 1200kg capacity
  • 750mm wide
  • 360mm high
  • Battery powered
  • Fully proportional remote control
  • 45° gradeability (100%)
  • 3Km/h maximum speed

Cranes for Hire at Caledonian Cranes, Scotland. 6

2200 R / 2200 PRO

Cranes for Hire at Caledonian Cranes, Scotland. 24

  • 2200kg capacity
  • 950mm wide
  • 365mm high
  • Battery powered
  • Fully proportional remote control
  • 45° gradeability (100%)
  • 3Km/h maximum speed

Cranes for Hire at Caledonian Cranes, Scotland. 6

Extending the Capabilities of the Tracked Carriers

Attachments include a Fifth Wheel & Dolly, Stair Climbing Kit, Winch, Swing Arm Jib, Dozer Blade, Tow Bar and an A-Frame Stillage, all available at Caledonian Cranes.

Cranes for Hire at Caledonian Cranes, Scotland. 6

Tracked Carriers 5th Wheel.
Tracked Carriers 5th Wheel.
tracked-carriers-stair-kit
Tracked Carriers Stair Climbing Kit
tracked-carriers-winch
Tracked Carriers Winch
tracked-carriers-jib
Tracked Carriers Swing Arm Jib
tracked-carriers-dozer-blade
Tracked Carriers Dozer Blade
Tracked-carriers-tow
Tracked Carriers Tow Bar
tracked-carriers-a-frm
Tracked Carriers A-Frame Stillage

Glass Robots for Hire

Glass Handling for Hire

Designed and built in Germany.

Glassworker GW 625-2

The Glassworker GW 625-2 from Uplifter is strongest off-road glass lifter of its class.

Cranes for Hire at Caledonian Cranes, Scotland. 27

  • Lifting capacity max. 625 kg
  • Max. lifting height (vertical) 3,10 m/3,60 m „Highlifter“
  • Max. lifting height (overhead) 3,60 m/4,20 m „Highlifter“
  • Individual arrangement of the suction cups
  • Hydraulic rotator as a optional feature
  • Standard wireless remote control for boom and suction disc movements
  • Self monitoring system

Cranes for Hire at Caledonian Cranes, Scotland. 6

Vacuum Cup UPG350

The Vacuum Cup UPG350 from Uplifter is specially designed for loads up to 350 kg.

Cranes for Hire at Caledonian Cranes, Scotland. 29

  • Horizontal load capacity max. 350 kg
  • Silicone-free suction plates (no marks)
  • Vertical load capacity max. 300 kg
  • Manual rotation by 360
  • Manual swivelling by 90
  • 2 independent vacuum circuits
  • 12 V battery power supply
  • Wooden transport box included
  • Own weight approx. 43 kg

Cranes for Hire at Caledonian Cranes, Scotland. 6

Vacuum cup UPG1000

The UPG1000 vacuum cup easily lifts loads of up to 1000 kg.

Cranes for Hire at Caledonian Cranes, Scotland. 31

  • Load capacity:
    4 suction plates = 400 kg
    6 suction discs = 600 kg
    8 suction plates = 800 kg
    10 suction plates = 1,000 kg
  • Silicone-free suction plates (no marks)
  • Suction plates with spring-loaded plunger and joint
  • Manual rotation 360° with grid every 90°
  • Manual swivelling without raster
  • Stepless swivelling from 0° to 90° by lowering cylinder
  • Removable support arm - unit depth min. 150mm
  • Two independent vacuum circuits with 2-fold safety
  • Integrated measuring devices for monitoring
  • Acoustic warning devices

Cranes for Hire at Caledonian Cranes, Scotland. 6

Download the Data Sheet for the Uplifter Vacuum cup UPG1000.

Cranes for Hire at Caledonian Cranes, Scotland. 33

Potain Cranes and Lifts for Hire

See below for an overview and downloads of data sheets for each crane.

Potain IGO21

Potain Igo 21

Technical Data
Cranes for Hire at Caledonian Cranes, Scotland. 34 Max. Under hook Height 19.3 m
Cranes for Hire at Caledonian Cranes, Scotland. 35 Payload max. 1,800 kg
Cranes for Hire at Caledonian Cranes, Scotland. 36 Power Phase S/3

Key Weight Capacity:

  • 12m extension = 1800kg
  • 26m extension = 700kg

Cranes for Hire at Caledonian Cranes, Scotland. 37

Potain IGO42

Potain IGO42

Technical Data
Cranes for Hire at Caledonian Cranes, Scotland. 34 Max. Under hook Height 23 m
Cranes for Hire at Caledonian Cranes, Scotland. 35 Payload max. 4000 kg
Cranes for Hire at Caledonian Cranes, Scotland. 36 Power Phase 3

Key Weight Capacity:

  • 10m extension = 4000kg
  • 36m extension = 1000kg

Cranes for Hire at Caledonian Cranes, Scotland. 37

Potain IGO 36

Cranes for Hire at Caledonian Cranes, Scotland. 42

Technical Data
Cranes for Hire at Caledonian Cranes, Scotland. 34 Max. Under hook Height 22 m
Cranes for Hire at Caledonian Cranes, Scotland. 35 Payload max. 4000 kg
Cranes for Hire at Caledonian Cranes, Scotland. 36 Power Phase 3

Key Weight Capacity:

  • 10m extension = 4000kg
  • 32m extension = 1100kg

Cranes for Hire at Caledonian Cranes, Scotland. 37

Potain IGO50

Potain IGO50

Technical Data
Cranes for Hire at Caledonian Cranes, Scotland. 34 Max. Under hook Height 23.2 m
Cranes for Hire at Caledonian Cranes, Scotland. 35 Payload max. 4000 kg
Cranes for Hire at Caledonian Cranes, Scotland. 36 Power Phase 3

Key Weight Capacity:

  • 12m extension = 4000kg
  • 40m extension = 1100kg

Cranes for Hire at Caledonian Cranes, Scotland. 37

Potain IGO T85

Potain T85

Technical Data
Cranes for Hire at Caledonian Cranes, Scotland. 34 Max. Under hook Height 38 m
Cranes for Hire at Caledonian Cranes, Scotland. 35 Payload max. 6000 kg
Cranes for Hire at Caledonian Cranes, Scotland. 36 Power Phase 3

Key Weight Capacity:

  • 13m extension = 6000kg
  • 45m extension = 1400kg

Cranes for Hire at Caledonian Cranes, Scotland. 37

Potain HUP32

Potain HUP32

Technical Data
Cranes for Hire at Caledonian Cranes, Scotland. 34 Max. Under hook Height 21.3-27 m
Cranes for Hire at Caledonian Cranes, Scotland. 35 Payload max. 4000 kg
Cranes for Hire at Caledonian Cranes, Scotland. 36 Power Phase 3

Key Weight Capacity:

  • 10.7m extension = 4000kg
  • 32m extension = 1000kg

Cranes for Hire at Caledonian Cranes, Scotland. 37

Potain HUP40-30

Potain HUP40-30

Technical Data
Cranes for Hire at Caledonian Cranes, Scotland. 34 Max. Under hook Height 25.6-30 m
Cranes for Hire at Caledonian Cranes, Scotland. 35 Payload max. 4000 kg
Cranes for Hire at Caledonian Cranes, Scotland. 36 Power Phase 3

Key Weight Capacity:

  • 13.2m extension = 4000kg
  • 40m extension = 1000kg

Cranes for Hire at Caledonian Cranes, Scotland. 37
